Pfostenträger Typ T04 extra stark in Beton

Made in Germany
GH-Post Base Type T04 90x105mm bar 70x323mm
ETA 16 0550 Made in Germany DC Statik

COLUMN BASE TYPE T04 EXTRA STRONG IN CONCRETE



*Structural calculation example (The load bearing capacities are only indicative. Detailed static information can be found in the upper section in documents / download)

Art. No. Post [mm] Pressure F1,Rk Tension F1,Rk F2/3,Rk F3/4,Rk
  min w min h Steel [kN]
19810210 140 136 283,0 111,0 30,0 10,7

 4 dowels Ø 12 mm

Column base type T04 extra strong in concrete show more
Order no.: 19810210 EAN: 4019346505700
Ø 13 mm: 2
Trägerplatte Breite: 120
Trägerplatte Stärke: 15
Schwert Breite: 90
Schwert Höhe: 105
Schwert Stärke: 8
Rohr Höhe: 323
Rohr Ø: 70
ETA-16/0550: ETA-16/0550
Material: S 235 JR
Nutzungsklasse: NKL 3
 Are you a customer or a new customer? (Specialist trade)
 For more information about our products, orders, invoices and promotions, log in to our new shop system (account above).



Ø 13 mm: 2
Trägerplatte Breite: 120
Trägerplatte Stärke: 15
Schwert Breite: 90
Schwert Höhe: 105
Schwert Stärke: 8
Rohr Höhe: 323
Rohr Ø: 70
ETA-16/0550: ETA-16/0550
Material: S 235 JR
Nutzungsklasse: NKL 3

equipment

GH-Rod Dowels 12x120 mm
ETA 16 0550 Made in Germany DC Statik

COLUMN BASE TYPE T04 EXTRA STRONG IN CONCRETE



*Structural calculation example (The load bearing capacities are only indicative. Detailed static information can be found in the upper section in documents / download)

Art. No. Post [mm] Pressure F1,Rk Tension F1,Rk F2/3,Rk F3/4,Rk
  min w min h Steel [kN]
19810210 140 136 283,0 111,0 30,0 10,7

 4 dowels Ø 12 mm
